1200V Modero Video Touch Panels
Installation and Upgrade of the Internal NXT Components
Upgrading the components within the Table Top panel involves removing the outer housing (with
speaker plate), removing and/or installing an existing component, and then placing the outer housing
back onto the NXT panel, as described in the following sections.
Step 1: Remove the existing NXT Outer Housing
1.
Carefully detach all connectors from the rear of the touch panel and then gently place the touch
panel LCD facedown onto a soft cloth to expose the under-side of the base (FIG. 16). This step
helps prevent scratching of the LCD.
2. Tilt the base forward so that both the bottom surface and Housing Screws are easily accessible and
then carefully remove the four plastic adhesive feet.
3. While holding the outer housing and base plate at a 45° (to prevent it from sliding), use a grounded
Phillips-head screwdriver to remove the eight Housing Screws.
NXA-PCI80211G Specifications (Cont.)
Receiver Sensitivity: • Using 802.11b communication:
1 Mbps: -86 dBm (max)
2 Mbps: -84 dBm (max)
5.5 Mbps: -83 dBm (max)
11 Mbps: -80 dBm (max)
• Using 802.11g communication:
1 Mbps: -86 dBm (max)
2 Mbps: -84 dBm (max)
5.5 Mbps: -83 dBm (max)
11 Mbps: -80 dBm (max)
Security: • 64-bit and 128-bit WEP
Availability: • All 1200V-Series and VG-Series NXT Table Top panels can be field upgraded
for wireless communication using the optional NXA-PCI80211G mini-PCI
card.
• Optional to the following NXD panels:
- NXD-1200V
- NXD-1200VG
- NXD-1500VG
- NXD-1700VG
Do not use Ethernet cables containing mounting boots. These boots could make
removal of the Ethernet connectors (from the panel) difficult and cumbersome.
Reference the location of the four plastic adhesive "feet". Once the outer housing is
placed back onto the panel, these "feet" must be placed back in their original
locations so they can fit into their provided openings on a Battery Base.
