3 Hardware configuration
48
Removing the front subchassis and rear
electronics bay
To remove the front subchassis
1 Disconnect all cables attached to the power distribution board and
to the mainboard.
2 With the front subchassis open, lift it straight up and clear of the
main chassis.
Label Description
A Front subchassis latch
B Mainboard cables
C Rear electronics bay
Figure 14 - Opening the front subchassis and rear electronics bay
