14. Service menu
When Broadcast mode ON, switch also Genlock to ON (Input → Input locking → Automatic + Options)and
enter the correct values for this source.
14.11 USB memory
What is possible with an USB device?
An USB device, FAT 16 formatted can be used, to save custom settings from the projector or to load custom settings to the projector.
This function is very handy to clone projectors.
The following settings can be transported via an USB device:
• baudrate
• address
• common address
• orientation
• text on/off
• file load mode
• eco mode & dimming
• rs232 interface & rs232 termination
• no signal setup settings
• IR receiver settings
• native resolution
• min delay
• current language of on screen menus
•customerid
• Network settings (DHCP, IP address, net mask, gateway address)
• blanking & keystone
• ScenergiX
• gamma
• color standard
• source switching
• effect settings
• broadcast mode
• menu position
• button settngs
• locking settings
Saving custom settings
1. Connect a FAT 16 formatted USB device to the USB port.
2. Press MENU to activate the menus.
3. Use the ▲ or ▼ key to select Service and press ENTER.
The service window opens.
4. Use the ▲ or ▼ key to select USB memory and press ENTER.
5. Use the ▲ or ▼ key to select Save custom settings and press ENTER.
178
R5976921 FLM R20+ PERFORMER 15/03/2010
