E. Specifications
E. SPECIFICATIONS
Overview
•Specifications FLM R20+ Performer
•Specifications FLM 5 cable input (multi purpose)
•Specifications FLM HDSDI – SDI input
•Specifications FLM DVI input
•Specifications FLM DVI HDCP input
E.1 Specifications FLM R20+ Performer
Overview
Light Output 18.000 ANSI Lumen
20.000 Center Lumen
Resolution
1400 x 1050 (native)
Contrast ratio 1800 : 1 (full field)
High contrast mode:
2400 : 1 (full field)
Lamp 3 kW Xenon
Warranty universal lamphouse: 750 Hrs
Ambient temperature Max 40°C (104°F)
Power consumption 3600 W
Mains Voltage 200 - 240 V
Weight 99 kg (220 lbs)
Dimensions WxLxH
707 x 1025 x 548 mm
(27.8 x 40.3 x 21.5 inch)
incl. carrying handle + rigging points
Noise Level
56 dBA (at 40°C)
ScenergiX Standard horizontal and vertical electronic edge blending
Network connection
10/100 base-T
Picture-in-picture 2 sources simultaneous
Input source compatibility
Max. input: up to QXGA (2048 x 1536)
Inputs Modular Inputs:
•Configurable 5 cable (BNC)
•DVI
• (HD)SDI (+ loop through)
Throw Ratio
Lens Throw ratio TLD (HB) 0.8 0.75 TLD (HB) 1.2 1.1 TLD (HB) 1.2+ 1.23 TLD (HB)
1.6 - 2.0 1.45 - 1.85 TLD (HB) 2.0 - 2.8 1.85 - 2.55 TLD (HB) 2.8 - 5.0 2.55 - 4.55 TLD
(HB) 5.0 - 8.0 4.55 - 7.3
Dust filters Dense, high quality microfilters available as spare kit, in a 6-pack & 24-pack
R5976921 FLM R20+ PERFORMER 15/03/2010 221
