6. Getting started
6. GETTING STARTED
About this chapter
This chapter describes the functions on the remote control and local keypad and gives an overview how to start up the projector. If
gives also a brief overview of the direct adjustment possible with these controls.
Overview
• RCU & Local keypad
• Terminology overview
• Operating the projector
• Using the RCU
• Quick setup adjustments
• Projector Address
• Source selection
• Controlling the Projector
6.1 RCU & Local keypad
How controlling the projector ?
The projector can be controlled by the local keypad or by the remote control unit.
Location of the local keypad ?
The local keypad is located on the input side of the projector.
Remote control functions.
This remote control includes a battery powered infrared (IR) transmitter that allows the user to control the projector remotely. This
remote control is used for source selection, control, adaptation and set up.
Other functions of the remote control are :
• switching between stand by and operational mode.
• switching to "pause" (blanked picture, full power for immediate restarting)
• direct access to all connected sources.
6.2 Terminology overview
Overview
The following table gives an overview of the different functionality of the keys.
R5976921 FLM R20+ PERFORMER 15/03/2010
43
