17. Removal of the projector covers
17.3 Removal of the lamp cover
WARNING: This procedure may only be performed by qualified technical service personnel.
Necessary tools
7mmflat screw driver.
How to remove the lamp cover of the projector ?
1. Release the two captive screws at the top and bottom right side of the lamp cover, using a flat screw driver.
Image 17-5
2. Remove the lamp cover from the projector doing the following:
a) gently pull out the left bottom corner (A) of the lamp cover,
b) then gently pull out the left top corner (B) of the lamp cover,
c) then move the lamp cover away from the projector (C).
Image 17-6
17.4 Removal of the input cover
WARNING: This procedure may only be performed by qualified technical service personnel.
Necessary tools
7mmflat screw driver.
How to remove the input cover of the projector ?
1. Release the two captive screws at the top and bottom left side of the input cover, using a flat screw driver.
R5976921 FLM R20+ PERFORMER 15/03/2010
195
