C. DMX chart
Chan-
nel
Function Value
Default
Actions
9 Zoom (LSB) 0 - 255 Fine zoom adjustment
0 - 7 Lamp power 100%
8 - 15 Lamp power 98%
16 - 23 Lamp power 96%
24 - 31 Lamp power 94%
32 - 39 Lamp power 91%
40 - 47 Lamp power 89%
48 - 55 Lamp power 86%
56 - 63 Lamp power 84%
64 - 71 Lamp power 82%
72 - 79 Lamp power 80%
80 - 87 Lamp power 78%
88 - 95 Lamp power 76%
96 - 103 Lamp power 74%
104 - 111 Lamp power 72%
112 - 119 Lamp power 70%
120 - 127 Lamp power 68%
128 - 135 Lamp power 66%
136 - 143 Lamp power 64%
144 - 151 Lamp power 62%
152 - 159 Lamp power 60%
160 - 167 No function
168 - 175 DMX buffer 4 (Not used)
176 - 183 DMX buffer 8 (Not used)
184 - 191 DMX buffer off (Not used)
192 - 199 DMX buffer clear (Not used)
200 - 207 No function
208 - 215 Power On / Lamp On (if held for 5 seconds)
216 - 223 Stand by / Lamp Off (if held for 5 seconds)
10 Control
224 - 255 No function
C.3 DMX chart, Full
Overview
Chan-
nel
Function Value
Default
Action
0 - 5 Mechanical shutter closed1 Intensity
6 - 255
Contrast 0 - channel 3
2 Brightness 0 - 255 128
Adjusts the brightness between 0 and 100% (SLM/XLM doesn’t
adjust on DVI)
3
Contrast
0 - 255 128 Together with channel 1
R5976921 FLM R20+ PERFORMER 15/03/2010 209
