C. DMX chart
C. DMX CHART
Overview
DMX chart, basic
DMX chart, Extended
DMX chart, Full
C.1 DMX chart, basic
Overview
Chan-
nel
Function Value Action
0 - 5 Mechanical shutter1 Intensity
0 - 255 Electronic contrast
2 Function selection 0 - 7 no function
8 - 15 Layout 1
16 - 23 Layout 2
24 - 31 Layout 3
32 - 39 Layout 4
40 - 47 Layout 5
48 - 55 Layout 6
56 - 63 Layout 7
64 - 71 Layout 8
72 - 79 Layout 9
80 - 87 Layout 10
88 - 95 Input select 1
96 - 103 Input select 2
104 - 111 Input select 3
112 - 119 Input select 4
120 - 127
128 - 135
136 - 143
144 - 151
152 - 159
160 - 167
168 - 175
176 - 183
184 - 207
208 - 215 Power On / Lamp On
216 - 223 Power Off / Lamp Off
224 - 255
