9. Tools Menu
Image 9-11
Select window with <PiP ADJUST>
Press <ENTER> to remove
Image 9-12
9.6 PiP layout
Overview
•PiPSave
PiP rename layout
PiP delete layout
9.6.1 PiP Save
What can be done ?
The active layout can be saved or "saved as".
When a new layout is
saved it is added to the PiP select menu.
A fixed layout can b
e edited (re-sizing, re-positioning,...) but it can not be saved under its original name.
How to save a layout ?
1. Press MENU to activate the menu bar.
2. Press to select the Tools item. (image 9-13)
3. Press to pull down the Tools menu.
4. Use or to select PiP layout.
5. Press to pull do
wn the menu.
6. Use or to select PiP save or save as.
7. Press ENTER.
If save as has been selected, a dialog box is displayed. (image 9-14)
Press ENTER to select the input field.
Use or to enter the name and exit with BACK or MENU. (numeric values can be added with the remote control)
If save has been sel
ected, a message box is displayed. (image 9-15)
