Barco R9010270 Projector User Manual



2. Installation Guidelines
PD
A
B
C
PD
Image 2-2
Front-Table configuration
A Side view
B Top view
CBackview
PD Distance projector - screen
2.3 Lenses
Overview
Lenses
Lens formulas
Lens installation
Cleaning the lens
2.3.1 Lenses
Available lenses
TLD HB lenses:
Lenses
Order number
TLD HB (0.8)
R9842040
TLD HB (1.6 - 2)
R9842060
TLD HB (2 - 2.8)
R9842080
TLD HB (2.8 - 5)
R9842100
TLD HB (5 - 8)
R
9642120
