3. Connections
3.2 Input Source Connections
Overview
• Input section
• Input facilities
3.2.1 Input section
Input Layers
The input section is divided in layers, each of them regrouping several inputs, this architecture allows the input section to be upgraded
at any time with an optional analog or digital layer.
1. Layer 1: analog layer containing analog data and video inputs.
2. Layer 2: a hybrid layer containing 2 digital and 1 analog input.
3. Layer 3 : (HD)SDI and interconnection.
4. Layer 4 : is interconnection layer, with XLR connection and an optional Ethernet connection.
3.2.2 Input facilities
overview
• 5–cable input
- component video (PR/Y/PB)
-RGBS
• composite video
•S-Video
• Digital Visual Input (DVI)
• Computer (analog RGB)
• Serial Digital Input or High Definition Serial Digital Input with loop through connection
22
R5976816 RLM R6+ PERFORMER 02/06/2006
