A. Standard Image Files
A. STANDARD IMAGE FILES
A.1 Table overview
Table overview
The following standard image files are pre-programmed in the projector.
Name
4
Fvert
Hz
5
FHor
kHz
6
Fpix
MHz
7
Ptot
8
Pact
9
Ltot
10
Lact
11
Video625 25,00 15,625 11,25 720 680 625 560
Video525 29,97 15,734 11,33 720 680 525 472
SDI_625
25,00 15,625 13,50 864 720 625 572
SDI_525
29,97 15,734 13,50 858 720 525 482
640x350@85
85,079 37,860 31,500 832 640 445 350
640x400@85
85,079 37,860 31,500 832 640 445 400
640x480@60
59,940 31,668 25,175 800 640 525 480
640x480@72
72,888 30,288 19,687 832 640 520 480
640x480@75
74,999 37,500 31,500 840 640 500 480
640x480@85
85,009 43,270 36,000 832 640 509 480
720x400@85
85,040 37,928 35,500 936 720 446 400
800x600@56
56,251 35,157 36,001 1024 800 625 600
800x600@60
60,317 37,879 40,000 1056 800 628 600
800x600@72
72,188 48,077 50,000 1040 800 666 600
800x600@75
75,001 46,876 49,501 1056 800 625 600
800x600@85
85,062 53,674 56,250 1048 800 631 600
1024x768@43
12
90,00 36,831 46,554 1264 1024 409 384
1024x768@60
60,004 48,363 65,000 1344 1024 806 768
1024x768@70
70.068 56,475 74,999 1328 1024 806 768
1024x768@75
75,030 60,024 78,751 1312 1024 800 768
1024x768@85
84,996 68,677 94,499 1376 1024 808 768
1152x864@75
74,999 67,499 107,999 1600 1152 900 864
1280x768@60
59,870 47,776 79,499 1664 1280 798 768
1280x768@75
74,992 60,288 102,249 1696 1280 805 768
1280x768@85
84,838 68,634 117,502 1712 1280 809 768
4. Name: name of file, contains the settings.
5. Fvert Hz: vertical frame frequency of the source
6. FHor kHz: horizontal frequency of the source
7. Fpix MHz: pixel frequency
8. Ptot : total pixels on one horizontal line.
9. Pact: active pixels on one horizontal line.
10. Ltot: total lines in one field
11. Lact: active lines in one field.
12. Interlaced
R5976816 RLM R6+ PERFORMER 02/06/2006 149
