9. Tools Menu
9. TOOLS MENU
Overview
• Overview of the Tools menu
• Introduction to PiP
• PiP select
• PiP add window
• PiP remove window
• PiP layout
•PiPAdjust
9.1 Overview of the Tools menu
Overview
• PiP select
- Full-screen
-2by2raster
- PiP layout 1
- PiP layout 2
- PiP layout 3
• PiP add window...
• PiP remove window...
• PiP layout
-Save
-Saveas
- Rename
-Delete
• PiP adjust
9.2 Introduction to PiP
PiP
PiP stands for "Picture in Picture" and allows to display multiple windows containing each of them an image. The
windows may be of the video or data type.
What are the different possibilities within the PiP mode ?
The input section of the RLM R6+ Performer projector allows a multitude of combinations of different input signals which may be
projected in the 4 windows of the PiP screen.
The PiP mode allows independent settings for each window:
• Image settings : contrast, brightness, tint, color, ...
• Vertical and horizontal shift of each window all over the screen
• Re-sizing of the window
• Digital Zoom
R5976816 RLM R6+ PERFORMER 02/06/2006
91
