4. Getting Started
No. Key name Description
10 Lens control
use these buttons to obtain the desired ZOOM, SHIFT, FOCUS.
11
VOL Used as lens shift left - right.
12 Picture controls use these buttons to obtain the desired picture analog level.
13
DIGI ZOOM allows a digital Zoom of a part of the image
14 FREEZE
press to freeze the projected image.
15 PIP
allows to activate the PICTURE IN PICTURE mode
16 ENTER
to confirm an adjustment or selection in the MENU.
On the local keypad and the RCU, the ENTER button additionally accesses the PIP
window re-size function
17
Cursor keys Cursor Keys on RCU or on the local keypad : to make menu selections or to access the
menu bar.
18
BACK to leave the selected menu or item (go upwards to previous menu).
19
EFFECTS
not yet implemented
20
PIP ADJUST allows to select a PiP window and change its configuration on screen
21
RC operating indication lights up when a button on the remote control is pressed. (This is a visual indicator to
check the operation of the remote control)
22 IR receiver IR receiver
Green
Red
Led 1 IR acknowledgement
Standby
Led 2 Hardware error
Led 3
Cool down sequence: flickers 60 seconds
after switching to standby
rescue program (software error)
4.2 Switching on
How to switch on.
1. Press the power switch to switch on the projector.
- When ’0’ is pushed in, the projector is switched off.
- When ’1’ is pushed in, the projector is switched on
The projector starts in standby mode, LED1 is red.
Starting image projection.
1. Press Standby key once on the local keypad or on the remote control.
Note: It may take about 60 seconds before ima
ge projection, i.e. no projection u ntil the completion of several operations (soft-
ware initialization,...).
Note: If the Security mode is enabled, a text box will be displayed for PIN code entry, see Security setting in the Installation
menu
Note: If Identification screen is on, the I
dentification screen will be displayed during s tart up.
CAUTION: Pushing the standby key
too long, might cause the projector to shut down right after an image is
displayed.
R5976816 RLM R6+ PERFORMER 02/06/2006 37
