14. Installation menu
2. Push the desired function key for 3 seconds.
The menu item is stored behind the quick access key. The message Quick Access key stored will be displayed.
14.6 RS baudrate
How to change the RS baudrate?
1. Press MENU to activate the menu bar.
2. Press → to select the Installation item. (image 14-14)
3. Press ↓ to pull down the Ins tallation menu.
4. Use ↑ or ↓ to select RS232 baudrate
5. Press → to pull down the menu.
6. Use ↓ or ↑ to select the desired baudrate.
7. Press ENTER to confirm.
Image 14-14
14.7 RS mode
How to change the mode?
1. Press MENU to activate the menu bar.
2. Press → to select the Installation item. (image 14-15)
3. Press ↓ to pull down the Ins tallation menu.
4. Use ↑ or ↓ to select RS mode
5. Press → to pull down the menu.
6. Use ↓ or ↑ to select the desired mode.
The following modes are possible:
- RS232
- RS422
- RS422 terminated
7. Press ENTER to confirm.
136
R5976816 RLM R6+ PERFORMER 02/06/2006
