16. Adjustment menu (check up)
16.2 Convergence
Only for check up of the convergence, no adjustment is possible in the field. When a convergence problem
occurred, contact a Barco service center.
How to select ?
1. Press MENU to activate the menu bar.
2. Press to select the Adjustment item. (image 16-2)
3. Press to pull down the Adjustment menu.
4. Use or to select Convergence.
5. Press to pull down the menu.
6. Use or to select the desired convergence test pattern.
7. Press ENTER to select.
The selected test pattern will be displayed.
Image 16-2
16.3 More..
Access
The items covered by More are only accessible for service technicians with a special key code.
