C. Specifications
Inputs Fixed inputs
• 1x Configurable 5-Wire (BNC)
• 1x Composite Video (BNC)
• 1x S-Video (4-pin mini-DIN)
• 1x analogue RGB (D15 connector)
• 1x SDI/HDSDI (+ loop through)
• 1x DVI (Digital Visual Interface)
Communication
• 1x RS-232C IN (D-9 connector)
• 1x RS-232C OUT (D-9 connector)
• 1x RS-232C IN (XLR connector)
• mini-jack for wired remote control
Compatibility
• All current video sources (PAL, SECAM, NTSC) in Composite, S-VHS, Component
or RGB formats
• All currently proposed HDTV, extended and improved television standards (1080i,
720p)
• All computer graphics formats from VGA, SVGA, XGA, SXGA,full HD to UXGA
• Most Macintosh computers
• Electronic workstations with a resolution up to 1600 x 1200 pixels at 75 Hz
• Most computer sources with a pixel clock up to 200 MHz
• DVIsourcesuptoSXGA+
Power Dissipation
Max 2217 BTU/h
AC power
90V - 255V
(50 Hz - 60Hz)
Features
• AutoImage
• Advanced picture-in-picture
• Seamless switching with effects
• Standard light shutter
• Advanced digital zoom
• Rigging point
• Carrying handle
• Frame
• P7 color processing
Screen size From 1-7m / 3-23ft.recomended
Scan Frequencies Pixel clock >162Mhz (UXGA 60hz)
Lenses
Lens Order Nr TLD (HB) 0.8 R9842040 TLD (HB) 1.6 - 2.0 R9842060 TLD (HB) 2.0 -
2.8 R9842080 TLD (HB) 2.8 - 5.0 R9842100 TLD (HB) 5.0 - 8.0 R9842120
Safety Regulations Compliant with UL1950 and EN60950
Electromagnetic Interference Complies with FCC rules & regulations, part 15 Class A and CE EN55022 Class A
Noise Level
42dBA (at 40°C)
Network connection
Optional (10 base-T)
Dust filters Metal filters
Outputs HDSDI/ SDI loop out
154 R5976816 RLM R6+ PERFORMER 02/06/2006
