12. Image Files Menu
12. IMAGE FILES MENU
Overview
• Overview of the Image Files Menu
• Introduction to image files
• Load file
• File selection
• Auto Image
• Edit file
• Rename file
• Copy
• Delete
• Automatic load
• Zoom-Focus
12.1 Overview of the Image Files Menu
Overview
• Load
• File selection
-Fit
-All
• Auto Image
• Edit...
• Rename...
• Copy...
• Delete...
•Zoom/Focus
- Universal
-Unique
12.2 Introduction to image files
Introduction
An image file contains the main characteristics of a source (number of active lines
,...). The projector’s memory contains a list of files
corresponding to the most common sources, these are the standard files (file extension= *.s). When a new source corresponds to
one of these files, a custom file (file extension=*.C) is created and saved for future use.
The maximum number of custom files that can be created is 99, the four last files are systematically overwritten.
When there is a little difference, the file can also be loaded and then edited until
the source specs are reached.
The AutoImage function creates automatically the best suited image file (
custom file) for a new source. Au-
toImage is used when:
- a new source is detected : AutoImage creates a new custom file which can always be edited if necessary.
- the AutoImage button on the RCU is pressed
AutoImage works only in full screen mode
If the AutoImage function does not succeed in finding a file and no file is loaded (load list is empty), which
means that the source is not displayed, then use the copy function,
R5976816 RLM R6+ PERFORMER 02/06/2006 109
