C. Specifications
C. SPECIFICATIONS
C.1 RLM R6+ Performer specifications
Overview
Light Output 6000 ANSI Lumen
6500 Center lumen
Resolution
1400 x 1050 (native)
Contrast ratio 1600:1 (full field)
Lamp
2 x 250 W mercury
Lamp warranty: 1000 hrs
Ambient temperature
Max 40°C (104°F)
Power consumption 700 W
Mains Voltage 92-240 V
Weight
Projector: 25 kg (56 lbs)
Frame:5kg(11lbs)
Dimensions WxLxH
705 x 707,8 x 316,5 mm
(27.8 x 27.9 x 12.5 inch)
Sealed DLP™ core Standard
ScenergiX Standard horizontal and vertical electronic edge blending
Picture-in-picture
Up to 4 sources simultaneously (2 data, 1 video and 1 SDI)
Lens encoders
On zoom and focus (with TLD lenses)
Input source compatibility
1600 x 1200 (max. input)
Throw Ratio
Lens Throw ratio (on RLM R6+) TLD (HB) 0.8 0.75 TLD (HB) 1.6 - 2.0 1.45 - 1.85 TLD
(HB) 2.0 - 2.8 1.85 - 2.55 TLD (HB) 2.8 - 5.0 2.55 - 4.55 TLD (HB) 5.0 - 8.0 4.55 - 7.3
Order Information Projector body (without lens): R9010270
Spare dual lamp: R9852940
Lens Order Nr TLD (HB) 0.8 R9842040 TLD (HB) 1.6 - 2.0 R9842060 TLD (HB) 2.0 -
2.8 R9842080 TLD (HB) 2.8 - 5.0 R9842100 TLD (HB) 5.0 - 8.0 R9842120
Brightness uniformity > 90% for the total screen
Display
3 Chip DLP SXGA+ (resolution of 1400 x 1050 pixels (aspect ratio 4:3)).
Lens Shift Vertical: -10% to +110%
Horizontal: -50% to +50%
(small differences occur per lens type)
On board display server
Not available
R5976816 RLM R6+ PERFORMER 02/06/2006 153
