Input 1 video type
Input 1 can only input composite video, other video types are not selectable.
Input 2 video type
Rotate either the Adjust horizontal ([) or Adjust vertical ({) knob while in the Input 2
submenu to select the appropriate video format (composite, S-video, YUVi, YUVp/HDTV,
YUV Auto) for input 2.
When input 2 is set to YUV Auto, the scaler detects if YUVi or YUVp/HDTV is applied and
sets the input accordingly. The default is YUVi video.
Input 3 video type
Input 3 can input only S-video, no other video types are selectable for this input. Using the
Input Configuration menu.
Input 4 video type
Rotate the Adjust horizontal ([) or vertical ({) knobs while in the Input 4 submenu to
select the appropriate video format (composite, S-video, RGBcvS, YUV, YUVp/HDTV, RGB
scaled, RGB pass-through, Auto detect).
NOTE: RGB pass-through signals (at the native rate without additional processing) are
available on analog outputs only. The DVI output is disabled for RGB pass-
through.
For DVS 304 DVI models, input 4 has an EDID emulation feature. See table on page 15 for
EDID values.
When input 4 is set as “auto detect”, the scaler will switch to the new conguration
whenever it detects an input type change. The default is RGB scaled.
SDI input (SDI IN)
Rotate either the Adjust horizontal ([) knob or Adjust vertical ({) knob while in the SDI
Input submenu to select the input # for the SDI input. The SDI input can be assigned to
inputs 1, 2, 3, 4, or none (*). The default is none.
NOTE: When the SDI input is no longer assigned to an input, either because it has
been assigned to a new input or is set to “none”, the input reverts to the last
video type that was assigned to it.
SDI de-interlacer options
Rotate either the Adjust horizontal ([) or Adjust vertical ({) knob while in the SDI Deinter
submenu to set the appropriate de-interlacing method (Standard or Flip). If the SDI input
is displayed with a significant amount of jaggies, use this setting to flip the odd and even
fields when de-interlacing the incoming SDI signal. The default is Standard.
DVS 304 Series • Operation 13
