IP Address
The DVS 304 IP Address eld contains the IP address of the connected scaler. This value is
encoded in the flash memory in the scaler.
Valid IP addresses consist of four 1-, 2-, or 3-digit numeric subelds separated by dots
(periods). Each eld can be numbered from 000 through 255. Leading zeroes, up to 3
digits total per eld, are optional. Values of 256 and above are invalid.
The default address is 192.168.254.254, but if this conicts with other equipment at your
installation, you can change the IP address to any valid value.
NOTE: Editing the Extron IP address while connected via the Ethernet port can
immediately disconnect the user from the scaler. Extron recommends
editing this eld using the RS-232 link and protecting the Ethernet access
to this screen by assigning an administrator’s password to qualified and
knowledgeable personnel only.
Edit this eld as follows:
1. Click in the DVS 304 IP address eld. The graphic cursor becomes a text cursor.
2. Edit the address as desired.
3. Press the Tab key on the keyboard or click in another field to exit the IP Address field.
4. Click on the Submit button to make the address change take affect.
Gateway IP Address
The Gateway IP Address eld identies the address of the gateway to the mail server to be
used if the DVS 304 and the mail server are not on the same subnet.
The gateway IP address has the same validity rules as the system IP address.
Subnet Mask field
The Subnet Mask eld is used to determine whether the DVS 304 is on the same subnet
as the controlling PC or the mail server when you are subnetting.
Date/Time Settings fields
The Date/Time Settings fields provide a location for viewing and setting the time functions.
The adjustable variables are month, day, year, hours, minutes, AM/PM, and (time) zone.
Change the date and time settings as follows:
1. Click the desired variable’s drop box. A drop down scroll box appears.
2. Click the desired value.
NOTE: For quick setting of the date and time, click the Local Date/Time.
Click Cancel at any point before submitting to exit any field changes.
The unit is not updated with those changes The screen refreshes and
shows the current device settings.
3. Repeat steps 1 and 2 for all variables that need to be changed.
DVS 304 Series • Ethernet Control 68
