Operation, cont’d
CrossPoint 450 Plus and MAV Plus Switchers • Operation
3-52
Worksheet example 2: Daily configuration
Figure 3-7 continues from worksheet example 1 by showing the ties that make up
the configuration of preset 1. Black lines shows one configuration, green lines a
second configuration, and red lines a third configuration.
In this example:
• The image of the presenter, from the main podium camera (input 1), is:
Displayed in the main hall (output 1)
Displayed in the conference room (output 4) to the overflow crowd
Displayed in the lobby (output 8)
Tied to the VCR (output 6)
• The presenter's microphone (input 3) is routed to the main hall, conference
room, and a VCR (outputs 1, 4, and 6):
• The presenter has a presentation on her laptop computer (input 4) that is:
Displayed in the main hall (output 2)
Displayed locally on the podium (output 3)
• Music from the CD player (input 5) is:
Played in the background in the main hall on sound system #2 (output 5)
Played in the lobby (output 8)
I
nput sources
Output destinations
Preset # Title:
Fill in the preset number and use colors, or dashes, etc. to make connecting lines. Indicate if the configuration is for Video, Audio, or both.
58 59 60 61 62 63 64 49 50 51 52 53 54 55 56 57
42 43 44 45 46 47 48 33 34 35 36 37 38 39 40 41
26 27 28 29 30 31 32 17 18 19 20 21 22 23 24 25
10 11 12 13 14 15 16 1 2 3 4 5 6 7 8 9
58 59 60 61 62 63 6449 50 51 52 53 54 55 56 57
42 43 44 45 46 47 4833 34 35 36 37 38 39 40 41
26 27 28 29 30 31 3217 18 19 20 21 22 23 24 25
10 11 12 13 14 15 161 2 3 4 5 6 7 8 9
Camera
main
podium
VTG
400
Rack DVD
(DVS)
PC1
RGB 201
Classrm
#1 VCR
DVS 406
Classrm
#2 VCR
DVS 406
Audio
CD
Laptop
RGB 201
Podium
mic
Camera
#2
Floorbox
#1-1
Floorbox
#1-4
Floorbox
#1-3
Floorbox
#1-2
Floorbox
#2-1
Floorbox
#2-4
Floorbox
#2-3
Floorbox
#2-2
Floorbox
#3-1
Floorbox
#3-4
Floorbox
#3-3
Floorbox
#3-2
Floorbox
#5-1
Floorbox
#5-4
Floorbox
#5-3
Floorbox
#5-2
Floorbox
#4-1
Floorbox
#4-4
Floorbox
#4-3
Floorbox
#4-2
Demo rk
#1
USP 405
Demo rk
#3
USP 405
Demo rk
#2
USP 405
Demo rk
#4
USP 405
Demo rk
#5
USP 405
Demo rk
#7
USP 405
Demo rk
#6
USP 405
Demo rk
#8
USP 405
Main
hall
PJ#1
Demo
rack
monitor
Class
room #1
monitor
Lobby
monitor
VCR
(USP 405)
Class
room #2
monitor
Sound
system
#2
Conf.
room
Podium
monitor
Main
hall
PJ#2
Demo
wallbox
#1-1
Demo
wallbox
#1-2
Demo
wallbox
#2-1
Demo
wallbox
#2-2
Demo
wallbox
#3-1
Demo
wallbox
#3-2
Demo
wallbox
#4-1
Demo
wallbox
#4-2
Demo
wallbox
#5-1
Demo
wallbox
#5-2
Demo
wallbox
#6-1
Demo
wallbox
#6-2
Demo
wallbox
#7-1
Demo
wallbox
#7-2
Demo
wallbox
#8-1
Demo
wallbox
#8-2
Demo
rack
switcher
Demo
room
PJ#!
Figure 3-7 — Worksheet example 2: Daily configuration
