Chapter 1 - Installation
1-8
1.7 Power Terminals
Type A Configuration: 1 ~ 5 HP (SV008ACtionMaster-2, SV015ACtionMaster-2, SV022ACtionMaster-2,
SV037ACtionMaster-2, SV008ACtionMaster-4, SV015ACtionMaster-4, SV022ACtionMaster-4, SV037ACtionMaster-4)
R S T G N B1 B2 U V W
Type B Configuration: 7.5 ~ 10 HP (SV055ACtionMaster-2, SV075ACtionMaster-2, SV055ACtionMaster-4,
SV075ACtionMaster-4)
R S T G P N B1 B2 U V W
Type C Configuration: 15 ~ 30 HP (SV110ACtionMaster-2, SV150ACtionMaster-2, SV185ACtionMaster-2,
SV220ACtionMaster-2, SV110ACtionMaster-4, SV150ACtionMaster-4, SV185ACtionMaster-4, SV220ACtionMaster-4)
R S T G P1 P2 N U V W
Symbols Functions
R
S
T
AC Line Voltage Input
(3 Phase, 200 ~ 230VAC or 380 ~ 460VAC)
G Earth Ground
P
Positive DC Bus Terminal
DB Unit (P-P
5
) Connection Terminals
(DB Unit may be added when more braking duty (More than 30%ED) is required)
P1
P2
External DC Reactor (P1-P2) and DB Unit (P2-P
6
) Connection Terminals
N
Negative DC Bus Terminal
DB Unit (N-N
7
) Connection Terminal
B1
B2
Dynamic Braking Resistor (B1-B2) Terminals
U
V
W
3 Phase Power Output Terminals to Motor
(3 Phase, 200 ~ 230VAC or 380 ~ 460VAC)
“Suitable for use on a circuit capable of delivering not more than 10,000 rms symmetrical amperes,
240 volts maximum for 230V class models and 480 volts maximum for 460V class models.”
6
This P terminal is provided on optional Dynamic Braking Unit.
7
This N terminal is provided on optional Dynamic Braking Unit.
