Toshiba MA-516-100 Cash Register User Manual



- 158 -
EO1-11116
MA-516-100 SERIES
28. Specifications
Size ................................................................................ 460 mm (width) x 430 mm (depth) x 319 mm (height including
rubber feet)
(or 352 mm (height) when Customer’s Display is popped up.)
--- with PSP Drawer
460 mm (width) x 400 mm (depth) x 314 mm (height including
rubber feet)
(or 347 mm (height) when Customer’s Display is popped up.)
--- with SP Drawer
Weight ........................................................................... 14.0 kg ...........with PSP Drawer
15.0 kg ...........with SP Drawer
Power Required ............................................................ AC 117V ± 10 %; 60Hz ± 10 %
Power Consumed ......................................................... 0.30 A (operating), 0.10 A (non-operating)
Ambient Temperature .................................................. 0°C to 40°C
Relative Humidity ......................................................... 10% to 90% RH (non-condensing)
Size of Receipt and Journal Rolls .............................. 45 mm (width) x max. 80 mm (diameter)
Validation Slip Spec.
Number of Sheets.............. 2 sheets (original + duplicate)
Thickness .......................... Non-carbon Slip .......... 0.07 mm to 0.12mm
Carbon Slip ................. 0.04 mm to 0.06 mm for both original sheet and duplicate sheet
Size.................................... 50 mm or more in height, 135 mm to 210 mm in width
* Use a slip which has no curl (especially on edges), no bend, no wrinkle.
Amount and Counter Totals In Report Memory
Daily
Operation Customer Periodical Report
Count Count Memory
(digits) (digits)
Financial Report Items Provided
Grand Total (non-resettable) 16 (except media-in-
Other Items NOTE 9 5 (+2 decimal) 5 5 drawer totals)
Reset Counter 4
Department 9 5 (+2 decimal) 5 Provided
PLU 9 5 (+2 decimal)
Reset Counter 4
Cashier Provided
Gross Sale 9 5 (+2 decimal) 5
Other Income Total 9 5 (+2 decimal)
Reset Counter 4
Hourly Range Sale 9 5
Reset Counter 4
NOTE: Some items have an Amount and a Counter, some have an Amount only, others have a Counter only. The counter
type varies depending on the item.
Memory Protection
Long-lasting rechargeable lithium battery for memory protection.
Specifications are subject to change without notice.
Amount Item Count
(digits) (digits)
Report
