3-8 DocuTech 128/155/180 HighLight Color Operator Guide
Routine maintenance
In U.S. markets
– 11.1 to 11.4 inches/282 to 290 mm
– 11.8 to 12.1 inches/300 to 307 mm
– 13 to 13.5 inches/330 to 343 mm
In non-U.S. markets
– 11.1 inches to 11.4 inches/282 to 290 mm
– 11.8 inches to 12.1 inches/300 to 307 mm
NOTE: With these paper sizes, transfer efficiency may be
reduced.
CAUTION: To avoid damage to the photoreceptor, you must set
the tray size with the transfer assist blade.
Installing the
custom transfer
assist blade
The custom transfer assist blade comes in a package containing
detailed instructions. Be sure you follow the instructions carefully.
CAUTION: To prevent damage to the system, have your service
representative show you the procedure before you attempt to
customize and install a transfer assist blade for the first time.
Setting tray size with
the custom transfer
assist blade
When you are using the custom transfer assist blade, you must
set the tray length. Use the following two tables to determine the
tray length setting to use.
Table 3-2. Tray length settings for custom transfer assist
blades (U.S. markets)
Table 3-3. Try length settings fro custom transfer assist
blades (Non-U.S. markets)
Paper Size Set Paper Size
11.5 to 11.7 inches/292 to 297 mm 11.7 inches/297 mm
12.1 to 12.9 inches/307 to 328 mm 13 inches/330 mm
13 to 13.9 inches/330 to 353 mm 14 inches/356 mm
Paper Size Set Paper Size
10 to 10.9 inches/254 to 277 mm 11 inches/279 mm
11.5 to 11.6 inches/292 to 294 mm 11.7 inches/3297 mm
12.1 to 12.9 inches/307 to 328 mm 13 inches/330 mm
