Installation
8
NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom
Removing the Faceplate
In certain circumstances, the Faceplate must be removed and replaced with a new faceplate. Because the
device is installed against a wall, the faceplate must be removed carefully to prevent the two top prongs
on the underside of the Faceplate from being broken. To remove the faceplate:
1. Gently lift up on the faceplate from the bottom. Do NOT pull up from the sides or the top.
2. Let the faceplate fall forward from the top of the device and let it pivot from the bottom.
3. Remove the faceplate from the two bottom prongs and install the new trim ring if necessary.
4. Place the Faceplate back onto the device. Make sure to align the Microphone, Light, and PIR
Motion sensor locations on the device to their respective openings on the Faceplate assembly.
