NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom
Checking the Panel Statistics
1.
Press the Tools button in the Protected Setup Navigation Buttons section. This opens the Tools
menu.
2. Within the Tools menu, press the Panel Statistics button. All connection statistics are contained on
this page, e.g., Received, Processed, and Dropped ICSP Messages.
Refreshing the Panel Statistics
1.
Press the Tools button in the Protected Setup Navigation Buttons section. This opens the Tools
menu.
2. Within the Tools menu, press the Panel Statistics button.
3. Push the Refresh button.
Clearing the Panel Statistics
1.
Press the Tools button in the Protected Setup Navigation Buttons section. This opens the Tools
menu.
2. Within the Tools menu, press the Panel Statistics button.
3. Push the Clear button.
4. Confirm the selection.
Panel Statistics Page (Cont.)
Total • Received - The total Blink messages received by the panel.
• Missed - The total Blink messages missed by the panel.
Last 15 Minutes • Received - The total Blink messages received by the panel in the last 15 minutes.
• Missed - The total Blink messages missed by the panel in the last 15 minutes.
Ethernet Statistics The Ethernet connection statistics for the panel.
Wireless Statistics Since the NXD-500i does not have wireless capability, this field is disabled.
Clear Clears all panel connection statistics.
Refresh Refreshes all panel connection statistics.
