NXD-500i Touch Panel Accessories
19
NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom
NXD-500i Touch Panel Accessories
The following section outlines and describes both the included accessories and other AMX equipment
available for the NXD-500i.
PS-POE-AF PoE Injector
The PS-POE-AF PoE Injector (FG423-80) is a single-port, self-contained Power-over-Ethernet (PoE)
power supply that delivers both DC power and data to PoE-equipped devices by “injecting” DC power
through a Cat5 Ethernet cable (FIG. 14). The PoE Injector allows devices such as the NXD-500i to
function without an additional power connection other than an Ethernet connection.
Power-over-Ethernet eliminates the need for an AC outlet at each device installation point, resulting in
easier and less expensive installation. It also can be used to extend the distance between the PoE devices
and standard power outlets by up to 328 feet (100 meters).
FIG. 14 PS-POE-AF Power-Over-Ethernet Power Supply
Each PoE Injector may be used for one device’s power needs. Multiple devices in a
network that require PoE will require multiple Injectors.
PS-POE-AF Specifications
Output Specifications
Combined Line and Load
Voltage Regulation
Excluding Cord ±1%
Ripple 1% Vp-p max.
Transient Response • 0.5ms for 50%
• Load Change Typical
Protection • Foldback Overcurrent Protection
• Short Circuit Protection
Input Specifications
AC Input Voltage Range 100-240VAC -10%, +6%
Line Frequency 47-63Hz
AC Input Current • 90VAC Input
•0.6A max.
Protection • Internal Primary Current Fuse
• Inrush Limiting
