Setup Pages and Descriptions
53
NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom
Time & Date Settings Page
The Time & Date Settings page (FIG. 39) allows setting and alteration of the time and date information
on the NetLinx Master. If either the Time or Date is modified on this page and then updated to the Master
by pressing the Set Time button, all devices communicating to that target Master will then be updated to
reflect the new information.
The elements of the Time & Date Setup page are as follows:
FIG. 39 Time and Date Settings page
Time Display
fields
Date Display
fields
Currently
selected
The only way to modify a panel’s time, without altering the Master, is through NetLinx
code.
Time & Date Setup Page Elements
Back: Returns to the previously active touch panel page without saving changes.
Connection Status icon: This visual display of the connection status allows the user to have a current
visual update of the panel’s connection status regardless of what page is
currently active.
• A Lock only appears on the icon if the panel has established a connection
with a currently secured target Master (requiring a username and password).
Time Date Refresh/Set: This section provides two options:
• The Get Time/Date button retrieves the Time and Date information from the
Master.
• The Set Time/Date button sets the Master to retain and save any time/date
modifications made on the Time & Date Setup page.
Time Display fields: • These fields display the time in three formats: STANDARD, STANDARD
AM/PM, and 24 HOUR.
Date Display fields: • These fields display the calendar date information in several different formats.
