NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom
Key features include:
Support of AMX's 4th generation (G4) graphics which provide higher brightness, richer
colors, and deeper contrast. The new G4 graphics technology is supported by the TPDesign4
Touch Panel Design application, available for download from www.amx.com.
Display of images on a large 16:9 image format, while providing a wide 90-degree top-to-
bottom viewing angle.
A front panel light sensor, motion sensor, IR receiver and a Sleep/Setup Access button.
Utilization of the Voice Over Internet protocol (VoIP), which allows telephone calls to be
made or received directly from the touch panel.
Support of AMX Computer Control, which enables remote viewing and control of any
networked computer directly from the panel. This gives the user the ability to launch digital
music from a PC, cruise the Internet, check and respond to E-mail, open software files, and
launch applications. Anything you can do on your PC can be accomplished through these
panels.
Programmable firmware that can be upgraded via the mini-USB port in the back of the device.
NXD-500i Specifications
The specifications for the 5" Widescreen Modero panel include:
Specifications for NXD-500i 5" Widescreen Video Touch Panel (FG2261-02)
Dimensions (HWD): • NXD-500i (with faceplate): 4.15" x 5.59" x 1.97"
(10.50 cm x 14.20 cm x 5 cm)
• CB-TP5i Rough-In/Wallbox (optional): 4.27" x 5.14" x 3.40"
(10.86 cm x 13.06 cm x 8.64 cm)
Power Requirements: • PoE Powered - No local Power Supply needed.
• Max power draw: 5.5W.
Memory (factory default): • 128 MB SDRAM
• 256 MB integrated Flash Memory (not upgradeable - factory programmed)
Weight: • 0.80 lbs (0.36 kg)
Certifications: • FCC Part 15 Class B
•CE
• IEC 60950
•RoHS
Panel LCD Parameters: • Aspect ratio: 16 x 9
• Maximum brightness (luminance): 200 cd/m
2
• Channel transparency: 8-bit Alpha blending
• Contrast ratio: 250:1
• Display colors: 256 thousand colors (18-bit color depth)
• Dot/pixel pitch: 0.14 mm
• Panel type: TFT Color Active-Matrix
• Screen resolution: 800 x 480 pixels (HV) @ 60 Hz frame frequency
• Viewing dimensions: 4.3" x 2.58" (109.2 mm x 65.2 mm)
Active Viewing Area: • 4.25” x 2.55” (10.80cm x 6.48cm)
Viewing Angles: • Up/Down/Left/Right: 40/80/60/60
IR Reception Angle: • Horizontal: +
25° (left and right from center)
• Vertical: +
15° (up and down from center)
Audio • G.711 sound standard
• 75dB SPL@1m
