Setup Pages and Descriptions
55
NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom
Supported sampling rates for WAV
The following is a listing of supported sampling rates associated for WAV files played on a NXD-500i
panel. Some WAV files currently played on other Modero panels may not work on a NXD-500i. The
supported sampling rates for WAV files are:
Volume Page Elements (Cont.)
Default Panel Sounds: Sets the panel to play various sounds.
• Activating the Button Hit button plays a default sound when touching an
active button.
• Activating the Button Miss button plays a default sound when touching a
non-active button or any area outside of the active button
• The Play Test Sound button plays a test WAV/MP3 file over the panel’s
internal speakers.
Intercom Mic Level: Allows adjustment of the current Microphone volume level being received from
the intercom.
• Use the UP/DN buttons to adjust the Microphone volume level
(range = 0 - 100).
• The Mic Out Level bargraph indicates the current Mic Out level.
Internal Sound Level: This section allows you to adjust the current sound level on the internal panel
speaker:
• Use the UP/DN buttons to adjust the volume output on the internal speakers
(range = 0 - 100).
• The Internal Sound Level bargraph indicates the current sound level.
• The Mute button mutes the volume.
Intercom Volume: This section allows alteration of the current intercom volume level:
• Use the UP/DN buttons to adjust the volume level (range = 0 - 100).
• The Master Volume bargraph indicates the current volume level.
• The Mute button toggles the Mute feature.
Supported WAV Sampling Rates
• 48000 Hz • 16000 Hz
• 44100 Hz • 12000 Hz
• 32000 Hz • 11025 Hz
• 24000 Hz • 8000 Hz
• 22050 Hz
