NXD-500i Touch Panel Accessories
20
NXD-500i 5" Wall/Flush Mount Touch Panel with Intercom
For more information, please refer to the PS-POE-AF PoE Injector Installation Guide, available at
www.amx.com.
PS-POE-AF Specifications (Cont.)
General Specifications
Topology • Switching-Fixed
• Frequency Flyback
Dielectric Withstand • Primary-Secondary 3000VAC, 4250VDC
• Secondary-Ground 500VDC
Spacing 5mm Primary-Secondary
Leakage Current Less than 250 uA
Efficiency • 65% Typical @ Max. Load
• and 120VAC/60 Hz
Weight (excluding cord)
7 Ounces (200 Grams)
Dimension • 5.24L x 2.13W x 1.42H (in)
• 133.0L x 54.0W x 36.0H (mm)
Case Material Black 94V0 Polycarbonate
Cord and Connectors Dual RJ45 jacks built into the enclosure
EMC Information
FCC • Part 15 Class B
• EN55022 Class B
Immunity ESD: EN61000-4-2
RS EN61000-4-3
EFT EN61000-4-4
Surge EN61000-4-5
CS EN61000-4-6
Voltage Dip EN61000-4-11
Harmonic EN61000-3-2
CE CE Compliant
Hold-up Time • @120VAC 10ms min. typ.
• @240VAC 40ms min. typ.
Storage Temperature -30° C to +85° C
Approvals and Standards -
Safety
• cULus: UL/CSA60950
• TUV: EN60950
• CE: LVD, EMCD
MTBF 100,000 Calculated Hours
Environmental Specifications
Thermal Performance • Operating Temperature 0° C to 40° C
• No Derating
• Convectional Cooling
• Non Vented Case
Relative Humidity Non-Condensing 5% to 95%
Altitude 0-10,000 feet
