8-6 External Connectors
Table 8-6
Monitor
Connector and Icon Pin Signal
54321
109876
15 14 13 12 11
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Red analog
Green analog
Blue analog
Monitor ID Bit 2
Ground
Ground analog
Ground analog
Ground analog
Not connected
Ground
Monitor ID Bit 0
Bi-directional Data (SDA)*
Horizontal sync
Vertical sync
Data clock (SCL)*
*For DDC support (I
2
C monitors)
