Address Line Pt
DNP
Ob
j
Description Range Units Type R/W
03957-03960 303 8 20 obsolete-TOU Prior Month Reg 5 VAhour (Quadrant 3) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
03961-03964 303 9 20 obsolete-TOU Prior Month Reg 5 VARhour (Quadrant 3) 0 VARh / -9,999,999,999,999,999 VARh
1 VAR
H
F20 R
03965-03966 304 0 30 TOU Prior Month Reg 5 Peak Demand Watt (Quadrant 1 + 4) +32767 Watt / 0 Watt 1/ 65536 W sec F7 R
03967-03968 304 1 30 TOU Prior Month Reg 5 Peak Demand Watt (Quadrant 2 + 3) 0 Watt / -32768 Watt 1/ 65536 W sec F7 R
03969-03970 304 2 30 TOU Prior Month Reg 5 Peak Demand VAR (Quadrant 1 + 2) +32767 VAR / 0 VAR 1/ 65536 VAR sec F7 R
03971-03972 304 3 30 TOU Prior Month Reg 5 Peak Demand VAR (Quadrant 3 + 4) 0 VAR / -32768 VAR 1/ 65536 VAR sec F7 R
03973-03974 305 0 30 TOU Prior Month Reg 5 Coin. Dmd. VAR to Peak Dmd. Watt (Q 1 + 4) +32767 VAR/ -32768 VAR 1/ 65536 VAR sec F7 R
03975-03976 305 1 30 TOU Prior Month Reg 5 Coin. Dmd. VAR to Peak Dmd. Watt (Q 2 + 3) +32767 VAR / -32768 VAR 1/ 65536 VAR sec F7 R
03977-03980 306 0 50 TOU Prior Month Reg 5 Peak Demand Watt (Q 1 + 4) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
03981-03984 306 1 50 TOU Prior Month Reg 5 Peak Demand Watt (Q 2 + 3) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
03985-03988 306 2 50 TOU Prior Month Reg 5 Peak Demand VAR (Q 1 + 2) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
03989-03992 306 3 50 TOU Prior Month Reg 5 Peak Demand VAR (Q 3 + 4) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
03993-03996 307 0 20 obsolete-TOU Prior Month Reg 6 Watthour (Quadrant 1 + 4) +9,999,999,999,999,999 Wh / 0 Wh
1 W
H
F20 R
03997-04000 307 1 20 obsolete-TOU Prior Month Reg 6 VAhour (Quadrant 1) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
04001-04004 307 2 20 obsolete-TOU Prior Month Reg 6 VARhour (Quadrant 1) +9,999,999,999,999,999 VARh / 0 VARh
1 VAR
H
F20 R
04005-04008 307 3 20 obsolete-TOU Prior Month Reg 6 VAhour (Quadrant 4) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
04009-04012 307 4 20 obsolete-TOU Prior Month Reg 6 VARhour (Quadrant 4) 0 VARh / -9,999,999,999,999,999 VARh
1 VAR
H
F20 R
04013-04016 307 5 20 obsolete-TOU Prior Month Reg 6 Watthour (Quadrant 2 + 3) 0 Wh / -9,999,999,999,999,999 Wh
1 W
H
F20 R
04017-04020 307 6 20 obsolete-TOU Prior Month Reg 6 VAhour (Quadrant 2) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
04021-04024 307 7 20 obsolete-TOU Prior Month Reg 6 VARhour (Quadrant 2) +9,999,999,999,999,999 VARh / 0 VARh
1 VAR
H
F20 R
04025-04028 307 8 20 obsolete-TOU Prior Month Reg 6 VAhour (Quadrant 3) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
04029-04032 307 9 20 obsolete-TOU Prior Month Reg 6 VARhour (Quadrant 3) 0 VARh / -9,999,999,999,999,999 VARh
1 VAR
H
F20 R
04033-04034 308 0 30 TOU Prior Month Reg 6 Peak Demand Watt (Quadrant 1 + 4) +32767 Watt / 0 Watt 1/ 65536 W sec F7 R
04035-04036 308 1 30 TOU Prior Month Reg 6 Peak Demand Watt (Quadrant 2 + 3) 0 Watt / -32768 Watt 1/ 65536 W sec F7 R
04037-04038 308 2 30 TOU Prior Month Reg 6 Peak Demand VAR (Quadrant 1 + 2) +32767 VAR / 0 VAR 1/ 65536 VAR sec F7 R
04039-04040 308 3 30 TOU Prior Month Reg 6 Peak Demand VAR (Quadrant 3 + 4) 0 VAR / -32768 VAR 1/ 65536 VAR sec F7 R
04041-04042 309 0 30 TOU Prior Month Reg 6 Coin. Dmd. VAR to Peak Dmd. Watt (Q 1 + 4) +32767 VAR/ -32768 VAR 1/ 65536 VAR sec F7 R
04043-04044 309 1 30 TOU Prior Month Reg 6 Coin. Dmd. VAR to Peak Dmd. Watt (Q 2 + 3) +32767 VAR / -32768 VAR 1/ 65536 VAR sec F7 R
04045-04048 310 0 50 TOU Prior Month Reg 6 Peak Demand Watt (Q 1 + 4) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
04049-04052 310 1 50 TOU Prior Month Reg 6 Peak Demand Watt (Q 2 + 3) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
04053-04056 310 2 50 TOU Prior Month Reg 6 Peak Demand VAR (Q 1 + 2) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
04057-04060 310 3 50 TOU Prior Month Reg 6 Peak Demand VAR (Q 3 + 4) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
Time of Use Prior Month Reg 6 Block
2- 74
