Address Line Pt
DNP
Ob
j
Description Range Units Type R/W
03313-03316 267 0 20 obsolete-TOU Frozen Reg 5 Watthour (Quadrant 1 + 4) +9,999,999,999,999,999 Wh / 0 Wh
1 W
H
F20 R
03317-03320 267 1 20 obsolete-TOU Frozen Reg 5 VAhour (Quadrant 1) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
03321-03324 267 2 20 obsolete-TOU Frozen Reg 5 VARhour (Quadrant 1) +9,999,999,999,999,999 VARh / 0 VARh
1 VAR
H
F20 R
03325-03328 267 3 20 obsolete-TOU Frozen Reg 5 VAhour (Quadrant 4) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
03329-03332 267 4 20 obsolete-TOU Frozen Reg 5 VARhour (Quadrant 4) 0 VARh / -9,999,999,999,999,999 VARh
1 VAR
H
F20 R
03333-03336 267 5 20 obsolete-TOU Frozen Reg 5 Watthour (Quadrant 2 + 3) 0 Wh / -9,999,999,999,999,999 Wh
1 W
H
F20 R
03337-03340 267 6 20 obsolete-TOU Frozen Reg 5 VAhour (Quadrant 2) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
03341-03344 267 7 20 obsolete-TOU Frozen Reg 5 VARhour (Quadrant 2) +9,999,999,999,999,999 VARh / 0 VARh
1 VAR
H
F20 R
03345-03348 267 8 20 obsolete-TOU Frozen Reg 5 VAhour (Quadrant 3) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
03349-03352 267 9 20 obsolete-TOU Frozen Reg 5 VARhour (Quadrant 3) 0 VARh / -9,999,999,999,999,999 VARh
1 VAR
H
F20 R
03353-03354 268 0 30 TOU Frozen Reg 5 Peak Demand Watt (Quadrant 1 + 4) +32767 Watt / 0 Watt 1/ 65536 W sec F7 R
03355-03356 268 1 30 TOU Frozen Reg 5 Peak Demand Watt (Quadrant 2 + 3) 0 Watt / -32768 Watt 1/ 65536 W sec F7 R
03357-03358 268 2 30 TOU Frozen Reg 5 Peak Demand VAR (Quadrant 1 + 2) +32767 VAR / 0 VAR 1/ 65536 VAR sec F7 R
03359-03360 268 3 30 TOU Frozen Reg 5 Peak Demand VAR (Quadrant 3 + 4) 0 VAR / -32768 VAR 1/ 65536 VAR sec F7 R
03361-03362 269 0 30 TOU Frozen Reg 5 Coin. Dmd. VAR to Peak Dmd. Watt (Quadrant 1 + 4) +32767 VAR/ -32768 VAR 1/ 65536 VAR sec F7 R
03363-03364 269 1 30 TOU Frozen Reg 5 Coin. Dmd. VAR to Peak Dmd. Watt (Quadrant 2 + 3) +32767 VAR / -32768 VAR 1/ 65536 VAR sec F7 R
03365-03368 270 0 50 TOU Frozen Reg 5 Peak Demand Watt (Q 1 + 4) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
03369-03372 270 1 50 TOU Frozen Reg 5 Peak Demand Watt (Q 2 + 3) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
03373-03376 270 2 50 TOU Frozen Reg 5 Peak Demand VAR (Q 1 + 2) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
03377-03380 270 3 50 TOU Frozen Reg 5 Peak Demand VAR (Q 3 + 4) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
03381-03384 271 0 20 obsolete-TOU Frozen Reg 6 Watthour (Quadrant 1 + 4) +9,999,999,999,999,999 Wh / 0 Wh
1 W
H
F20 R
03385-03388 271 1 20 obsolete-TOU Frozen Reg 6 VAhour (Quadrant 1) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
03389-03392 271 2 20 obsolete-TOU Frozen Reg 6 VARhour (Quadrant 1) +9,999,999,999,999,999 VARh / 0 VARh
1 VAR
H
F20 R
03393-03396 271 3 20 obsolete-TOU Frozen Reg 6 VAhour (Quadrant 4) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
03397-03400 271 4 20 obsolete-TOU Frozen Reg 6 VARhour (Quadrant 4) 0 VARh / -9,999,999,999,999,999 VARh
1 VAR
H
F20 R
03401-03404 271 5 20 obsolete-TOU Frozen Reg 6 Watthour (Quadrant 2 + 3) 0 Wh / -9,999,999,999,999,999 Wh
1 W
H
F20 R
03405-03408 271 6 20 obsolete-TOU Frozen Reg 6 VAhour (Quadrant 2) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
03409-03412 271 7 20 obsolete-TOU Frozen Reg 6 VARhour (Quadrant 2) +9,999,999,999,999,999 VARh / 0 VARh
1 VAR
H
F20 R
03413-03416 271 8 20 obsolete-TOU Frozen Reg 6 VAhour (Quadrant 3) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
03417-03420 271 9 20 obsolete-TOU Frozen Reg 6 VARhour (Quadrant 3) 0 VARh / -9,999,999,999,999,999 VARh
1 VAR
H
F20 R
03421-03422 272 0 30 TOU Frozen Reg 6 Peak Demand Watt (Quadrant 1 + 4) +32767 Watt / 0 Watt 1/ 65536 W sec F7 R
Time of Use Frozen Reg 6 Block
Time of Use Frozen Reg 5 Block
2- 68
