Address Line Pt
DNP
Ob
j
Description Range Units Type R/W
05129-05130 373 0 30 TOU Current Month Reg 4 Coin. Dmd. VAR to Peak Dmd. Watt (Q 1 + 4) +32767 VAR/ -32768 VAR 1/ 65536 VAR sec F7 R
05131-05132 373 1 30 TOU Current Month Reg 4 Coin. Dmd. VAR to Peak Dmd. Watt (Q 2 + 3) +32767 VAR / -32768 VAR 1/ 65536 VAR sec F7 R
05133-05136 374 0 50 TOU Current Month Reg 4 Peak Demand Watt (Q 1 + 4) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
05137-05140 374 1 50 TOU Current Month Reg 4 Peak Demand Watt (Q 2 + 3) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
05141-05144 374 2 50 TOU Current Month Reg 4 Peak Demand VAR (Q 1 + 2) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
05145-05148 374 3 50 TOU Current Month Reg 4 Peak Demand VAR (Q 3 + 4) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
05149-05152 375 0 20 obsolete-TOU Current Month Reg 5 Watthour (Quadrant 1 + 4) +9,999,999,999,999,999 Wh / 0 Wh
1 W
H
F20 R
05153-05156 375 1 20 obsolete-TOU Current Month Reg 5 VAhour (Quadrant 1) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
05157-05160 375 2 20 obsolete-TOU Current Month Reg 5 VARhour (Quadrant 1) +9,999,999,999,999,999 VARh / 0 VARh
1 VAR
H
F20 R
05161-05164 375 3 20 obsolete-TOU Current Month Reg 5 VAhour (Quadrant 4) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
05165-05168 375 4 20 obsolete-TOU Current Month Reg 5 VARhour (Quadrant 4) 0 VARh / -9,999,999,999,999,999 VARh
1 VAR
H
F20 R
05169-05172 375 5 20 obsolete-TOU Current Month Reg 5 Watthour (Quadrant 2 + 3) 0 Wh / -9,999,999,999,999,999 Wh
1 W
H
F20 R
05173-05176 375 6 20 obsolete-TOU Current Month Reg 5 VAhour (Quadrant 2) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
05177-05180 375 7 20 obsolete-TOU Current Month Reg 5 VARhour (Quadrant 2) +9,999,999,999,999,999 VARh / 0 VARh
1 VAR
H
F20 R
05181-05184 375 8 20 obsolete-TOU Current Month Reg 5 VAhour (Quadrant 3) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
05185-05188 375 9 20 obsolete-TOU Current Month Reg 5 VARhour (Quadrant 3) 0 VARh / -9,999,999,999,999,999 VARh
1 VAR
H
F20 R
05189-05190 376 0 30 TOU Current Month Reg 5 Peak Demand Watt (Quadrant 1 + 4) +32767 Watt / 0 Watt 1/ 65536 W sec F7 R
05191-05192 376 1 30 TOU Current Month Reg 5 Peak Demand Watt (Quadrant 2 + 3) 0 Watt / -32768 Watt 1/ 65536 W sec F7 R
05193-05194 376 2 30 TOU Current Month Reg 5 Peak Demand VAR (Quadrant 1 + 2) +32767 VAR / 0 VAR 1/ 65536 VAR sec F7 R
05195-05196 376 3 30 TOU Current Month Reg 5 Peak Demand VAR (Quadrant 3 + 4) 0 VAR / -32768 VAR 1/ 65536 VAR sec F7 R
05197-05198 377 0 30 TOU Current Month Reg 5 Coin. Dmd. VAR to Peak Dmd. Watt (Q 1 + 4) +32767 VAR/ -32768 VAR 1/ 65536 VAR sec F7 R
05199-05200 377 1 30 TOU Current Month Reg 5 Coin. Dmd. VAR to Peak Dmd. Watt (Q 2 + 3) +32767 VAR / -32768 VAR 1/ 65536 VAR sec F7 R
05201-05204 378 0 50 TOU Current Month Reg 5 Peak Demand Watt (Q 1 + 4) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
05205-05208 378 1 50 TOU Current Month Reg 5 Peak Demand Watt (Q 2 + 3) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
05209-05212 378 2 50 TOU Current Month Reg 5 Peak Demand VAR (Q 1 + 2) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
05213-05216 378 3 50 TOU Current Month Reg 5 Peak Demand VAR (Q 3 + 4) Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R
05217-05220 379 0 20 obsolete-TOU Current Month Reg 6 Watthour (Quadrant 1 + 4) +9,999,999,999,999,999 Wh / 0 Wh
1 W
H
F20 R
05221-05224 379 1 20 obsolete-TOU Current Month Reg 6 VAhour (Quadrant 1) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
05225-05228 379 2 20 obsolete-TOU Current Month Reg 6 VARhour (Quadrant 1) +9,999,999,999,999,999 VARh / 0 VARh
1 VAR
H
F20 R
05229-05232 379 3 20 obsolete-TOU Current Month Reg 6 VAhour (Quadrant 4) +9,999,999,999,999,999 VAh / 0 VAh
1 VA
H
F20 R
05233-05236 379 4 20 obsolete-TOU Current Month Reg 6 VARhour (Quadrant 4) 0 VARh / -9,999,999,999,999,999 VARh
1 VAR
H
F20 R
Time of Use Current Month Reg 5 Block
Time of Use Current Month Reg 6 Block
2- 85
