GE EPM 9650/9800 Computer Monitor User Manual



Address Line Pt
DNP
Ob
j
Description Range Units Type R/W
46350 Flicker Base Frequency R
46351-46372 Reserved R
46373-46376 Internal Input 1 Pulse Accumulation Unit Label R
46377-46380 Internal Input 2 Pulse Accumulation Unit Label R
46381-46384 Internal Input 3 Pulse Accumulation Unit Label R
46385-46388 Internal Input 4 Pulse Accumulation Unit Label R
46389-46392 Internal Input 5 Pulse Accumulation Unit Label R
46393-46396 Internal Input 6 Pulse Accumulation Unit Label R
46397-46400 Internal Input 7 Pulse Accumulation Unit Label R
46401-46404 Internal Input 8 Pulse Accumulation Unit Label R
46405-46408 Internal Input Pulse Aggregation 1 Unit Label R
46409-46412 Internal Input Pulse Aggregation 2 Unit Label R
46413-46416 Internal Input Pulse Aggregation 3 Unit Label R
46417-46420 Internal Input Pulse Aggregation 4 Unit Label R
46421-46422 Relay 1 Combination Tree Input Line 1, Point 1 R
46423-46424 Relay 1 Combination Tree Input Line 2, Point 2 R
46425-46426 Relay 1 Combination Tree Input Line 3, Point 3 R
46427-46428 Relay 1 Combination Tree Input Line 4, Point 4 R
46429-46430 Relay 1 Combination Tree Input Line 5, Point 5 R
46431-46432 Relay 1 Combination Tree Input Line 6, Point 6 R
46433-46434 Relay 1 Combination Tree Input Line 7, Point 7 R
46435-46436 Relay 1 Combination Tree Input Line 8, Point 8 R
46437 Relay 1 Combination Logic (Combination A/ Combination B) R
46438 Relay 1 Combination Logic (Combination C/ Combination D) R
46439 Relay 1 Combination Logic (Combination E/ Combination F) R
46440 Relay 1 Combination Logic (Combination G/ Reserved) R
46441 Relay 1 Set Delay/ Reset Delay R
46442-46444 Reserved R
46445-46446 Relay 2 Combination Tree Input Line 1, Point 1 R
46447-46448 Relay 2 Combination Tree Input Line 2, Point 2 R
46449-46450 Relay 2 Combination Tree Input Line 3, Point 3 R
Internal Input Pulse Accumulation Unit Label Block
ElectroLogic Block
2- 160
