Address Line Pt

DNP

Ob

j

Description Range Units Type R/W

05975 414 4 30 Analog Input 5, Module 4 +327.67% / -327.68% 0.01% F10 R

05976 414 5 30 Analog Input 6, Module 4 +327.67% / -327.68% 0.01% F10 R

05977 414 6 30 Analog Input 7, Module 4 +327.67% / -327.68% 0.01% F10 R

05978 414 7 30 Analog Input 8, Module 4 +327.67% / -327.68% 0.01% F10 R

05979 415 0-15 1 Limit States, Combinations, 1-16 F34 R

05980 415 16-31 1 Limit States, Combinations, 17-32 F34 R

05981-05984 416 0 50 Relay Logic Block Time Stamp 12/31/9999 23:59:59.99 10 msec F3 R

05985 417 0-15 1 Relay Logic States, Input 1, Relays 1-16 F34 R

05986 418 0-15 1 Relay Logic States, Input 2, Relays 1-16 F34 R

05987 419 0-15 1 Relay Logic States, Input 3, Relays 1-16 F34 R

05988 420 0-15 1 Relay Logic States, Input 4, Relays 1-16 F34 R

05989 421 0-15 1 Relay Logic States, Input 5, Relays 1-16 F34 R

05990 422 0-15 1 Relay Logic States, Input 6, Relays 1-16 F34 R

05991 423 0-15 1 Relay Logic States, Input 7, Relays 1-16 F34 R

05992 424 0-15 1 Relay Logic States, Input 8, Relays 1-16 F34 R

05993 425 0-15 1 Relay Logic States, Gate A, Relays 1-16 F34 R

05994 426 0-15 1 Relay Logic States, Gate B, Relays 1-16 F34 R

05995 427 0-15 1 Relay Logic States, Gate C, Relays 1-16 F34 R

05996 428 0-15 1 Relay Logic States, Gate D, Relays 1-16 F34 R

05997 429 0-15 1 Relay Logic States, Gate E, Relays 1-16 F34 R

05998 430 0-15 1 Relay Logic States, Gate F, Relays 1-16 F34 R

05999 431 0-15 1 Relay Logic States, Gate G, Relays 1-16 F34 R

06000 432 0-1 30 Delay Timer, Relay 1 / Relay 2 F35 R

06001 432 2-3 30 Delay Timer, Relay 3 / Relay 4 F35 R

06002 432 4-5 30 Delay Timer, Relay 5 / Relay 6 F35 R

06003 432 6-7 30 Delay Timer, Relay 7 / Relay 8 F35 R

06004 432 8-9 30 Delay Timer, Relay 9 / Relay 10 F35 R

06005 432 10-11 30 Delay Timer, Relay 11 / Relay 12 F35 R

06006 432 12-13 30 Delay Timer, Relay 13 / Relay 14 F35 R

06007 432 14-15 30 Delay Timer, Relay 15 / Relay 16 F35 R

06008 433 0-15 1 Desired Relay States, Relays 1-16 F36 R

Relay Logic Block

Limit Combination Block

2- 92
