Chapter 7: Programming 7-59
PACESETTER Plus Information
The PACESETTER Plus optional feature of the NCR 7870
Scanner/Scale determines what is wrong with a bar code label, fixes it,
and then transfers the information to the host terminal. In addition, the
scanner keeps track of what is wrong with the labels.
Mode 1 - Inquiry
Mode 1 keeps the following tallies. Included are the maximum counts.
Tally Count Type Description
Maximum
Count
C1 Good Reads 1,000,000
C2 No reads due to lack of a full label
(bars missing, folded label, etc.)
65,535
C3 Good reads with very highly
overprinted bars
65,535
C4 Good reads with very highly
underprinted bars
65,535
C5 Missing margins 65,535
Enter Mode 1 by scanning the Mode 1 tag. Tally counts are displayed
on the Integrated Display or the NCR 7825 Remote Display. First the
display shows the tally count number and the percentage of that count
to the number of good reads. Three seconds later the actual tally count
is displayed. This cycle continues every three seconds.
