13-14 Productivity Features
MA4000 Installation Manager User Guide - Revision 6
Step 4 Use the drop-down menus in the Secondary pane to edit any of the
following items for the selected backup station when connected to the
Secondary backup PBX:
—FPC
—PNUM
—IP-KIND
—TN
—SFC
—RSC
—STN
Step 5 (Optional) Use the Remove Tertiary Data check box to delete existing
data for the tertiary backup station.
Step 6 (Optional) Use the drop-down menus in the Tertiary pane to edit any of
the available items for the selected backup station when connected to
the Tertiary backup PBX.
Step 7 In the Name Display pane, do one of the following:
—Enter a name which will display when the back
up station is connected
to the secondary or tertiary PBX.
—Select the No Name Display option button
to specify that no name will
display when the backup station is connected to the secondary or
tertiary PBX.
—Select the Use
Primary's Name Display option button to specify that
the selected backup station will display its primary name when
connected to the secondary or tertiary PBX.
Step 8 Use the Key Template drop-down menu to specify which key template
the backup station will use when connected to the secondary or tertiary
PBX you can specify that the station will use no template, or a key
template that was previously defined in the Key Template tab, or a
customized template with no name.
If you choose to create a template with no name then that template applies only to
the backup station you are editing and will not be available to other backup stations
or listed in the Key Template tab. In essence, you are creating a "one-time-only"
template.
Step 9
Use the MAC Address field to change the backup station's Machine
Access Code address.
Step 10 (Optional - for TEC type 26 only) In the VPS Settings pane, use the text
fields to enter the voice mail port number (VPSNO) and channel
(VPSCH).
Step 11 Click Modify to save the edited data. Installation Manager saves the
edited station data and displays the station name in the status list with a
blue background, signifying the data has been modified but not yet
uploaded.
