3-42 Graphical User Interface
MA4000 Installation Manager User Guide - Revision 6
Primary Sections
The buttons located along the left side of the graphical user interface in
the Main window (see Figure 3-47) contain the core functions of MA4000
Installation Manager. This is where you will view, manipulate, and
prepare the data to be sent to the system.
Figure 3-47
Primary Sections Tabs
When a button is selected, a tab view appears for each running
horizontally across the top (see Figure 4-1). This information is a logical
break down of the main button selected on the left.
The following chapters will describe in detail every button and its
purpose.
