Graphical User Interface 3-39
MA4000 Installation Manager User Guide - Revision 6
License Verification Tool ...
The License Verification Tool provides a brief summary of the primary
licenses that are available (and in use) on your SV7000 system.
To launch the License Verification Tool, do the following:
Step From Microsoft Desktop, select Start > Programs > Installation
Manager R24 > License Verification Tool.
OR
Step From the Installation Manager Menu Bar, click Tools > License
Verification Tool ....
Clipboard...
Installation Manager now provides experienced users with integrated
access to the MAT Clipboard application. You can use this tool to access
MAT commands and transfer information directly to the Voice Server or
work offline and upload all changes at once.
The Clipboard can save command data from the Voice Server as XML
(Extensible Markup Language) files. You can then edit the XML files
using Microsoft Excel and upload the modified data back to the Voice
Server. Many MAT commands are time-consuming when programmed
individually. Using the Clipboard to download and upload the command
data in a single operation can make many tasks more efficient. For
example:
• Create an off-line XML file containing a large number of new users,
configu
red using the ASDT and AKYD commands, then upload the file
to the Voice Server.
• Transfer data from an old Voice Server to a new Voice Server by
downloading user data, edit
ing it off-line, then uploading it to the new
Voice Server.
For more complete information on using the Clipboard, refer to its user
documentation.
The Clipboard application (Figure 3-45) speeds system installations and
eliminates errors by importing data from one switch to a destination
switch.
NOTE
This tool is for planning purposes only and should not be construed as any legal
definition of the number of licenses that a customer has purchased or is entitled.
REFERENCE
