9315 UPS (500–750 kVA) Installation and Operation Manual S 164201244 Rev E www.powerware.com
14-1
Chapter 14 Product Specifications
The following sections detail the input, output, environmental, and battery
specifications for the UPS.
14.1 Model Numbers
The UPS systems are housed in free‐standing, double‐front cabinets with safety
shields behind the doors. The UPS systems are available in 50/60 Hz with various
output power ratings. Smaller models within a system may be upgraded in the field to
larger models:
System Models Notes
Powerware 9315‐625 562, 500, 450, 400 kW 50/60 Hz
Powerware 9315‐750 675, 600, 562, 500 kW 60 Hz only
14.2 UPS System Input
Operating Input Voltage
(Nominal +10/–15%)
600 Vac for operation from 510 Vac to 660 Vac (60 Hz only)
480 Vac for operation from 408 Vac to 528 Vac (60 Hz only)
400 Vac for operation from 340 Vac to 440 Vac (50/60 Hz only)
Operating Input Frequency
Range
"3 Hz of nominal (50 Hz or 60 Hz)
Operating Input Current Battery Charge
125% of full load for overload + battery charge
Actual load + 25% of full load for battery charge with 0.8 pF
output units
115% of full load for overload + battery charge
Actual load + 15% of full load for battery charge with 0.9 pF
output units
Reduced for Generator
Adjustable, set to 102%
Input Current Harmonic
Content
5% THD at full load (with input filter option installed)
Power Walk‐In Adjustable 3–60 second rectifier ramp‐up to full utility load
Power Factor Minimum 0.85
Line Surges 6 kV OC, 3 kA SC per ANSI 62.41 and IEC 801‐4
