INSTALLATION REFERENCE
EATON Powerware
®
9315 UPS (500–750 kVA) Installation and Operation Manual S 164201244 Rev E www.powerware.com
A-3
DIMENSIONS ARE IN MILLIMETERS [INCHES]
2080
[82]
1600
[63]
364.4
[14.3]
171.0
[6.7]
364.4
[14.3]
171.0
[6.7]
FRONT VIEW
Figure A‐2. Inverter/Rectifier Cabinet – PCM 1 Dimensions
