INSTALLATION REFERENCE
EATON Powerware
®
9315 UPS (500–750 kVA) Installation and Operation Manual S 164201244 Rev E www.powerware.com
A-25
DC RECTIFIER LINK
POSITIVE
DC RECTIFIER LINK
NEGATIVE
DC RECTIFIER LINK
POSITIVE
DC RECTIFIER LINK
POSITIVE
DC RECTIFIER LINK
NEGATIVE
DC RECTIFIER LINK
NEGATIVE
INVERTER #1
INVERTER #2
INVERTER #3
NOTE Metal shield covering power wiring terminals and battery compartment must be
removed to gain access to wiring terminals.
J6 (SYNC REF)
CONNECTION TO MBC
Figure A‐15. Output/Inverter Cabinet – PCM 2 Terminals (continued)
