INSTALLATION REFERENCE
EATON Powerware
®
9315 UPS (500–750 kVA) Installation and Operation Manual S 164201244 Rev E www.powerware.com
A-29
BATJ1
1
10
1
1
10
10
BATJ2
CB2TB
BATJ4
CB2 - AUX #1
CONTROL - 120
CONTROL - NEUTRAL
SHUNT TRIP
SHUNT TRIP
BATTERY DISCONNECT OPEN - RETURN
CB2 - CLOSE
CB2 - AUX #1
BATTERY DISCONNECT OPEN
ON GENERATOR RETURN
NO SYNC
OPEN FILTER - RETURN
ON GENERATOR
NO SYNC RETURN
OPEN FILTER
BREAKER CHARGE
POWER
Battery Terminal Board
Battery I/O Board
Figure A‐18. Inverter/Rectifier Cabinet – PCM 1 Customer Interface Wiring
