INSTALLATION REFERENCE
EATON Powerware
®
9315 UPS (500–750 kVA) Installation and Operation Manual S 164201244 Rev E www.powerware.com
A-23
AC SOURCE INPUT
DC SOURCE INPUT
FRONT
LEFT SIDE
REAR
CUSTOMER
ACCESS PANEL
E4
(POS)
E5
(NEG)
E1
(ØA)
GND
X-SLOT
E2
(ØB)
E3
(ØC)
Figure A‐13. Inverter/Rectifier Cabinet – PCM 1 Terminals (continued)
