6. PROGRAMMING OPERATIONS EO1-11152
6.6 PLU Table Programming (Submode 4)
6-18
DEPARTMENT TABLE PROGRAMMING CONTENTS (continued)
Address No.
Description of Programming Contents
9 Sub-link Department Code
• This entry is useful when the department item entry should always be followed by another
department’s item sale. If the department is not applied to this case, skip this address entry.
Refer to the following examples of applications.
HEAD-LINK DEPT.
SUB-LINK DEPT.
Example 1) Dept. 1 (for Bottle Drink Dept. 2 (for Bottle Deposit entries)
Net Content Sales entries)
Example 2) Dept. 14 (Battery drive Dept. 27 (Batteries)
Clocks)
As shown in the examples, this feature prevents the cashier from forgetting to enter the Sub-
link Dept. item attached to the Head-link Dept. item. And at the same time, in reports, two
Department Totals are separately read.
• In setting, enter the Sub-link Department Code (1 to 99). (The Main-link Dept. is the dept.
now being programmed.)
[#]
1 to 99 (Sub-link Department Code)
• To cancel the sub-linking, enter 0 instead of the Sub-link Dept. Code before [#].
REMARKS:
1) When the Head-link Dept. item is entered in a sale, an entry through the Sub-link Dept.
will be required. No other operations will be accepted until the Sub-link Dept. is
operated.
2) The HEAD-to-SUB linkage is effective for only one step. If the Sub-link Dept. is further
set with another Sub-link Dept., the first HEAD item will only require its own Sub-link
Dept. entry.
3) It is possible to set multiple departments are Head-link to one Sub-link Department.
(For example, multiple departments are assigned for bottled drink entries but only one
department is assigned for bottled-deposit entries.)
4) The Sub-link Dept. alone may be operated for sale entries, skipping the Head-link
Dept., without affecting the Head-link Dept. sales memory.
5) Various declaration keys, multiplications, etc. may be operated on each of the Head-link
and Sub-link depts., independently from the other.
6) When the [ITEM CORR] key is operated immediately after the Head-link item entry, the
Sub-link compulsory status will also be canceled.
7) When the [ITEM CORR] key is operated immediately after the compulsory Sub-link
item entry, an error will result.
8) Repeat entries will not be allowed on either the Head-link or Sub-link item.
9) Dollar Discount, %+, and %- may be operated on the Sub-link item as well as the Head-
link item.
10) When the Head-link dept. is programmed with “Single-item” status and a Single-item
receipt has been issued accordingly, the Sub-link dept. entry will not be compulsory.
11) An entry of any PLU linked to the Head-link dept will not require the Sub-link dept entry.
12) If Store Coupon is entered through the Head-link dept, the Sub-link dept entry will not
be compulsory.
13) When the Sub-link dept entry is compulsory, Store Coupon may be entered through the
Sub-link dept.
14) When the Sub-link dept is not memory-opened, the Head-link dept entry will result in an
error.
