4. ADDITIONAL FUNCTION KEY AND REGISTERING PROCEDURE EO1-11152
4. ADDITIONAL FUNCTION KEY AND REGISTERING PROCEDURE
4- 1
4. ADDITIONAL FUNCTION KEY AND REGISTERING
PROCEDURE
The following is the key that can be installed on the Master Terminal of an in-line system, in addition to the
standalone specifications, and the registering procedure using the key.
RTR (Register-to-Register) DECLARATION Key ([RTR])
By depressing the [RTR] key on the Master Terminal, various in-line jobs (DLLs, Consolidated Read/Reset
Report takings, etc.) can be performed.
PROCEDURE ON A MASTER TERMINAL FOR RTR DECLARATION
Mode Lock: SET, REG, X, Z, MGR or - /Anytime outside a sale
Depress [RTR]
NOTES: 1. While a PC job is under way ( a command of ULL, DLL, or Read/Reset from the PC), this RTR
Declaration is not possible. Similarly, while this RTR Declaration is on, no PC jobs are possible.
2. While the RTR Declaration is on, no transaction entries in “REG”, “MGR”, or “ - “ mode are
possible.
3. While the RTR Declaration is on, no Backup Data Check is performed.
4. While the RTR Declaration is on, the following are jobs to be allowed:
• Programming Operations
• DLL Operations (DLL to Satellite Terminals)
• Consolidated Read/Reset Report takings
• Manual Copying of Backup Data
5. The [RTR] key can be programmed to require Manager Intervention.
6. If the option “Auto Data Copying feature” is selected for Copying of Backup Data, the RTR
Declaration is not possible while a backup data update process is under way.
7. If the option “Compulsion of Data Sending to PC” is selected, the RTR Declaration is not possible
until sending the reset data (the consolidation data) to PC is completed.
By depressing the [RTR] key on the Master Terminal when the RTR Declaration is on, the RTR Declaration
ON status is canceled.
PROCEDURE ON A MASTER TERMINAL FOR RTR DECLARATION CANCEL
Mode Lock: SET, REG, X, Z, MGR or - / RTR Declaration is ON
Depress [RTR]
NOTE: If the Backup Error Flag is ON (the standard error message is “PLEASE BACK UP”), it means that
manual copying of Backup Data is required, and therefore the RTR Declaration Cancel is not
accepted until copying is completed.
RTR
