Persona C16 Card Printer Service Manual (Rev. 5.0)
198
Removing and replacing the Idler Springs on the C11 Card Printer with the
Magnetic Encoder (continued)
Step Procedure
4 Remove the four (4) screws, the Idler Spring (810480), the Roller (810236),
and any washers or spacers. Set aside the black spacer (D830033) for later
use.
5 Follow these steps to install the new parts for the idler spring closest to the
Magnetic Encoder:
a. Install two (2) washers (F000289). (Note: Install one (1) washer on each
post.)
b. Install one (1) spacer (D830033: black plastic). See page 14.
c. Install the Roller.
d. Install one (1) Idler Spring (D830068) on top of Roller.
e. Fasten two screws (F000170) with two (2) washers (140040) to each Post.
Caution No. 1: Do not over-tighten the screw.
Caution No. 2: When installing the Springs, ensure that the Spring is
centered about the centerplate tabs. This ensures that the tabs do not
interfere with the Spring.
Continued on the next page
